Chain Link Roller Shutter

At Britannia Retail, we manufacture high quality, industrial strength Roller Shutters. These Steel Electric Roller Shutters are perfect for Shopfronts, Garage doors, back yards, work shops, farm buildings, Offices, Banks, Receptions, Bars, Kitchens, Schools and any commercial site.

These Roller Shutters are manufactured from 22SWG galvanised steel and electrically operated by Key Switch or Rocker Switch, depending on preference. These Shutters come with internal manual override built onto the motor as standard, which allows you to wind up the door manually from inside the building in the event of power failure.

The shutters will be manufactured to suit your exact requirements & security needs. We have two fitting styles (Fix between and Plant on). The shutters can be installed onto brick work, steel work & wood dependant on the strength of the build. Our in house coating facility means we can provide a range of colour options in a format that will last and not peel off due to the manufacturing process.

If a heavier grade lath is required then we would recommend looking at our Industrial style Roller Shutters that have a thicker gauge lath and heavier duty motors as standard for an extra layer of security.

• Manufactured from aluminium tubes and links on aluminium rods.
• Tube size 111mm x 13mm;
• Link size 86mm x 16mm x 3mm;
• Steel guides 65mm x 32mm or 50mm x 32mm;
• Aluminium T-section Bottom rail.
• 100mm 16swg motor barrel assembly with lost bobbin dummy end

• L or T section galvanised steel bottom rail
• 240volt single phase tubular motor
• Internal manual override facility
• Fitting instructions are provided & we also offer a telephone technical support service to help with your install.
• 305mm Squared flag-plates
• Safety Brakes are a required feature is the Shutter is used as an access point/Pedestrian walkway.

Click to download the TECHNICAL SPECIFICATION
